Lockable gas spring Feature: Lockable gas springs can be locked anywhere along the complete stroke. By pushing the release pin, the piston valve opens allowing gas or oil to flow through the piston and the piston rod extends or can be pushed in. When the release pin is no longer being pushed, the valve closes independently and the piston rod is locked in the desired position. When the locking force is exceeded, the locking function in no longer given.
Place of Origin: Jiangsu, China
Brand Name: SGY
Style: Cylinder
Material: Steel
Usage: Industrial; Furniture; Automobile
Application: Furniture; auto and rail seat back recline control
Surface treatment: QPQ
Certificate: ISO9001/ ROHS/ IATF16949
Size: Customer's Requirement
OEM: Offered
Warranty: 3 Years
Type: Gas Charged
Delivery time: Sample in 7 days
Inside: Oil In Gas Spring
Packing: Carton
Supply Ability: 40000 Piece/Pieces per Day
Port: Shanghai
Adjustment lockable gas spring/gas strut support for furniture and car compression Product Description
Name | Gas spring |
Quality | 180,000 times -passed TUV fatigue test |
ROHS certificated by SGS |
Passed ISO9001 and ISO/TS 16949 International Quality System Certification |
Use
|
Automobile, Auto, car, Furniture, Machines, mechanical equipment, Boat, container, etc. |
Material |
steel/ ss304/ ss316 |
Color | silver/ black/ others |
Connector | ball connector/ metal eye/ clevis and so on |
Feature | Seat angle adjustment |
Noisy free |
Smooth operation |
Advantage | pass 180,000 times fatigue times |
we can supply samples for free |
Competitive price |
Fast delivery time |
The size can be made according the customer requirement |
Product NO. | Extended Length (mm) | Stroke (mm) | DIA (mm) | Force (N) |
SGY | 100-300 | 30-100 |
12*4 | 5-100 |
SGY | 300-600 | 100-200 | 15*6 | 10-30 |
SGY | 600-900
| 200-300 | 18*8 | 50-600 |
SGY | 900-1200
| 300-400 | 22*10 | 100-1200 |
SGY | 1200-1600 | 400-500 | 25*12 | 100-1800
|
SGY | 1600-2000 | 500-600 | 28*14 | 100-3000
|
SGY | 2000-2500 | 600-700 | 28*16 | 100-3000
|
SGY | 2500-3000 | 700-900 | 40*20 | 300-4000 |
We can do customized just according to your requests |
Adjustment lockable gas spring/gas strut support for furniture and car compression Service:
Free samples:
All the samples are free, just freight will be undertaken by your side. Or you can arrange global express company to pick up the samples from our factory. If you have your own size, welcome you send us your samples, we can make sample and production accordingly.
Customization:
Customization service are available, we will made the customized according to your drawing or samples. Our company has hundreds of sets of non-standard abrasive tools, all of which are made for customers before, because our customized products are also very cheap, because you do not need to re-open the abrasive tools, so it can reduce the cost of non-standard products for you.
Multiple payment and trade terms:
FOB Shanghai or CIF price if you need T/T, L/C, D/P, etc.
Delivery:
15 days in regular season
21 day in peak season
